Machining and Special Process Services for Gas Turbine and Aero Engine Components
Eldim delivers a comprehensive range of machining and manufacturing services for high-performance turbine components in the aerospace and energy sectors. Backed by all necessary certifications, including NADCAP and EN9100, our facilities in Hungary and the Netherlands combine advanced automation with strategic cost efficiency to meet the most demanding customer requirements.
We support the full production lifecycle—from design input and prototyping to industrialization and quality assurance—through vertically integrated capabilities within Eldim and the broader Oerlikon Group. This integration allows us to maintain strict control over cost, quality, delivery performance, and coating solutions.
Our manufacturing capabilities include:
- laser cutting,
- CNC turning & milling,
- 3- and 5-axis grinding,
- wire and sink EDM
- stamping
- sheet metal fabrication and assembly
We offer both conventional and nonconventional machining methods, supported by our in-house OEM-certified laboratory. Specialized techniques such as high-temperature vacuum processing, honeycomb structure integration, and component assembly are also available. These joining and reinforcement processes are carried out using advanced thermal and structural methods designed to meet the stringent requirements of aerospace and energy applications.
Our lean manufacturing approach ensures flexibility in adapting to design changes and evolving specifications, while consistently delivering high-quality components on time. Whether for mass production, small-batch manufacturing, or MRO services, Eldim provides tailored solutions that meet the highest industry standards.
| NL | HU | UK | Partner | ||
|---|---|---|---|---|---|
| Conventional Machining | CNC Turning | ♦ | |||
| CNC Milling | ♦ | ♦ | |||
| CNC Turning-Milling | ♦ | ||||
| Round Grinding | ♦ | ||||
| Honeycomb Grinding | ♦ | ♦ | |||
| 3-axis CNC grinding | ♦ | ||||
| 5-axis CNC grinding | ♦ | ||||
| Non-Conventional Machining | Sink EDM | ♦ | ♦ | ♦ | |
| Wire EDM | ♦ | ♦ | ♦ | ||
| EDM Fast Hole drilling | ♦ | ||||
| Laser Cutting | ♦ | ||||
| Honeycomb Laser Welding | ♦ | ♦ | |||
| Waterjet Cutting | |||||
| Sheet metal forming | Hydraulic Pressing | ♦ | |||
| Mechanical Pressing | ♦ | ||||
| Coining | ♦ | ||||
| Roll Forming | ♦ | ||||
| Hydroforming | ♦ | ||||
| Spin Forming | ♦ | ||||
| Welding | Ball Tack | ♦ | ♦ | ||
| TIG | ♦ | ♦ | |||
| Automated TIG | ♦ |
| NL | HU | UK | ||
|---|---|---|---|---|
| Heat Treatment Brazing | Vacuum Heat Treatment | ♦ | ♦ | |
| High Temp Vacuum Treatment | ♦ | ♦ | ||
| Hydrogen Furnance/Sintering | ♦ | |||
| Surface Treatment Cleaning | Grit Blasting | ♦ | ♦ | |
| Vibro Tumbling | ♦ | ♦ | ||
| Super Polish | ♦ | |||
| Alkaline Clean | ♦ | ♦ | ||
| Inspection | Fluor Penetrant Inspection | ♦ | ♦ | |
| CMM Inspection | ♦ | ♦ | ||
| Laboratory | ♦ | ♦ | ||
| Air Flow Inspection | ♦ | ♦ | ||
| Atos/GOM scanning | ♦ | ♦ | ||
| Simulation Software | NX CAM Verification (3-axis) | ♦ | ||
| NX CAM Simulation (5-axis milling) | ♦ | |||
| Siemens Plant Simulation "Digital Twin" | ♦ | |||
| Vericut (5-axis griding) | ♦ | ♦ | ||
| Vericut Simulation for Machining Center | ♦ | |||
| Automatization | Machining, large rings up to o900[mm] | ♦ | ||
| Machining, small rings up to o400[mm] | ♦ | |||
| Grinding & Deburring LPT/HPT segments | ♦ | |||
| Tack Joining HC/Rings | ♦ | |||
| Marking Segments | ♦ | |||
| 5 Axis Machining | ♦ | |||
| Vertical Integration | Additive Manufacturing | ♦ | ♦ | |
| Thermal Spray Coating | ♦ | ♦ | ♦ | |
| Thin Film Coating | ♦ | ♦ | ♦ |
